BELT ALIGNMENT DETECTOR
Ex ATEX (II 2 D) IP67 T80°C
SPECIFICATIONS
-
1. Detection
- Integrated inductive detector
- Activated by physical belt contact with the sensor
-
2. Installation
- Installed outside the elevator leg per pair (supplied with gasket and bolts)
- Casing opening of ø55mm on the rising leg
- Bolt center to center: 51×51mm
- Bolt ø: M6
- 2 wires NC/NO
STANDARDS
- ATEX 21/20
- Eligible for standard 2014/34/UE
- EN/IEC 60079-0
- EN/IEC 60079-31
- IP6X-IEC 60529
